SKY T (Twin column) Series - Key Feature

• The sky 7T & 6T machine is a Twin column edm machine suitable for large die.

• The time required to complete the dies is halved due to the simultaneous operation of two controllers on a single die.

• Semi cnc machine that allows sparking to be performed in the X,Y and Z-axis.

• All axes on both controllers are powered by AC servo motors for smooth movement.

• Auto Programmable Multi Cavity Operations in both controllers.

• Single Screen easy to use operation. Industrial TFT LCD colour  display on both controllers.

• High precision LM blocks and Ball screw for X,Y and Z-axis .

• Total of 100 programs, each program can do a single step, or a maximum of 10 steps machining (option) and each step includes 12 kinds of machining parameters in both controllers.

• Integral design with compact footprint. Closed Grain, stress relieved

• Casting for co-ordinate table.

• Automatic parameter selection as per machining and current requirement.

• Reduced Electrode wear with High MRR Due to Multi-Level Bi-Pulse Technology.

•  Selectable High Speed Jump Function.

•  Safety interlocks.

•  Less Maintenance cost.
